Baileigh HSP-33M Hydraulic Workshop Press

Stock Code: HSP-33M
MPN: HSP-33M

Descriptions

The HSP-33M is in our line of motorised H-frame presses. This heavy-duty press is built in Europe using only the best quality components and craftsmanship, a fully welded 3/8 plate steel frame is designed to handle the 30 tons of force the industrial-grade hydraulic system can generate. This heavy-duty commercial press is designed to be worked hard, and weighing in at 385kgs of sturdy construction, it is designed to last for years constant use.

The robust 1.5kw 400 volt, three phase motor provides the press with two working speeds, a rapid descent speed and a slow working speed. It is also supplied with a hand pump for precision work. This is a feature-rich high-quality European-made hydraulic workshop press.

Hydraulic operation
30 metric tons of pressure

Specifications

Item Number HSP-33M
Return Speed 16.7 mm / sec.
Maximum Pressure 166 bar
Motor 1.5 kW
Piston Head Diameter 100 mm
Pump Speed .871 / 3.619 / gal/min.
Oil Capacity 30 liters
Working Width .086″ / sec.
System Oil Capacity 8 liters
Lowering Speed .362″ / sec.
Maximum Capacity 60 ton
Cylinder Stroke 380mm
Cylinder Movable Yes
Cylinder Diameter 209 mm
Rpm 3000
Power 400V / 3-Phase
Shipping Weight 395
