HMT V85T VERSADRIVE Magnetic Drill 230V

Stock Code: HMT850085-P-230
MPN: 850085-P-230
EAN / GTIN: 5060451527834

Descriptions

The HMT VersaDrive® V85T is the first UK Built portable drilling machine range designed for the 21st century, designed to meet a need in the market for a high-performance, low maintenance, industrial quality portable drilling unit and to deliver constant performance in the most challenging drilling environments and fabrication conditions. Combining light weight and portability with a high power all day broaching capability up to 85mm diameter is combined with a forward reverse, variable speed motor that will tap holes up to M27 diameter. Fully rated for reaming, countersinking, and tapping. Advanced British electromagnets provide enhanced magnet hold for exceptional safety and stability.

Features & Benefits:

• All-day broaching capability up to 80mm diameter • Forward and reverse • Variable speed motor • Variable Torque control

Specification:

CUTTER SIZE RANGE- 12-85mm MAX CUTTER CAPACITY – 85mm TCT TWIST DRILL CAPACITY - 27mm MAX TAP CAPACITY – M27 LENGTH- 325mm WIDTH- 240mm HEIGHT- 425-645mm STROKE- 220mm WEIGHT- 20.5Kg MAGNET SIZE- 200x100mm MAGNETIC FORCE- 1750 Kg MOTOR POWER- 1800 W SPEED/s (RPM)- 1) 60-140 2) 200-470 RPM SPINDLE- MT3 ARBOR- 19.05mm (3/4”) Weldon TAKES CHUCK- Yes COOLANT SYSTEM – Gravity Oil Fed
